What is the application of a gear motor?
Electric gear motors are used in various applications that require high output torque and low output rotation speed. A gear motor is a combination of an electric motor with a gear reducer box.
This gear motor is an ideal drive for all kinds of industrial automation products for both industrial and commercial applications. We provide steady quality products with quiet and efficient performance alongside engineering solutions.
Main Product Range:
Induction motors, reversible motors, DC brush gear motors, DC brushless gear motors, CH/CV medium gear motors, planetary gear motors, worm gear motors, right angle solid and hollow shaft gear motors, etc. These are widely used in manufacturing pipelines, transportation, food, medicine, printing, fabric, packing, office apparatus, and entertainment equipment.
| Model | Gear Head | Rated Power (W) | Voltage (V) | Ampere (A) | Speed (r/min) | Torque (mN.m) | Shell Dia (mm) |
|---|---|---|---|---|---|---|---|
| GDM08-SC | 4GN | 30 | 12 | 4.6 | 1500 / 1800 / 2200 | 190.9 / 159.08 / 130.2 | Φ69 |
| 24 | 2.1 | 1500 / 1800 / 2200 | 190.9 / 159.08 / 130.2 | Φ69 |
| Reduction Ratio | L1 (Motor Body) | L2 (Gearbox) | L3 (Total Length) |
|---|---|---|---|
| 1:3 ~ 1:20 | 105mm | 32mm | 137mm |
| 1:25 ~ 1:300 | 105mm | 44mm | 149mm |
